Anvil drainage fittings have sufficient sweep to allow free unobstructed flow. They are made with a shoulder of the same diameter as the inside of the pipe, in accordance with ASME B16.12, Type 1. Thus, continuous passage is created when the pipe is screwed to the shoulder, leaving no place for solid matter to collect and clog in the pipe.
FIG 729 729 Sanitary Tees 90° Reducing Double Short Turn
727, 729 & 730 Y-Branches & Tee Submittal
718 90° Street Elbow
723 Reducing Tee
753 Coupling
735 Y-Branch 45° Reducing
702 90° Long Turn Elbow
701R 90° Reducing Short Turn Elbow
706 45° Long Turn Elbow
726 Sanitary Tees 90° Short Turn
702A 90° Extra Long Turn Elbow
707 22 1/2° Elbow
