FIG 65SR & 66SR Standard Weight Rigid Coupling with “C” Gasket

Std Rigid Gacket 65 SR P Enlarge
Description

• Maximum working pressure depending on coupling size and schedule of pipe:

  • 1" to 6" - 1000 psi (68.9 bar)
  • 8" - 800 psi (55.1 bar)
  • 10" & 12" - 600 psi (41.3 bar)
  • 14" to 20" - 300 psi (20.6 bar)
  • 24" - 250 psi (17.2 bar)

• UL Listed & FM Approved – 1" thru 12"

• All housings, gaskets and bolts identified by SCI logo

• Gasket Grade E - EPDM (green stripe) -30˚F (-34˚C) to +230˚F (+110˚C)

• Gasket Grade T - Nitrile (orange stripe) -20˚F (-29˚C) to +180˚F (+82˚C)

• Gasket Grade O - Fluoroelastomer (blue stripe) +20°F (-6°C) to +300°F (+149°C)

• Ductile iron housings conform to ASTM A-536 Grade 65-45-12

• Groove dimensions to AWWA C-606

• Finishes: Orange enamel paint

  • Hot dipped galvanized conforming to ASTM A-153
